CHOOSE YOUR IDEAL RFID Label

OSRFID is a company that provides RFID Inlay&Label solutions. We focus on the development and manufacturing of soft HF/NFC/UHF labels and inlays. We have a 9,000 square meter factory and offer competitive factory prices.

Inlays are the key to label performance. They are composed of antenna structures and chips. We use inlay images inside the labels to represent label products. Inlays with different antenna structures and chip models can meet the needs of different application scenarios. You can consult our RFID experts according to your needs.

We only develop inlays and soft labels (supplement: paper cards and PVC labels, cloth labels can also be made). We also support ODM and OEM, and can customize the substrate, glue, and printing process of various labels.

You can contact us to get free samples. Or refer to the article on label selection recommendations to choose an ideal label.

home

Product Type

Applications

Frequency

China brand chips

Global brand chips

Antenna Size in mm

Die-cut Dimension

User Memory

EPC Memory

TID Memory

Showing 1–10 of 35 results

  • Download file
    Download
    Inquiry
    Applications: Retail / Logistics / Pharmaceutical and Healthcare
    Details
    Product OS4216-U9
    ANTENNA SIZE(mm) 42*16mm
    Chip NXP UCODE 9
    Real Range (FCC) 8m
    EPC Memory 96Bits
    TID Memory 96Bits
    IC Life 100,000 programing cycles/50 years data retention
    RFID UHF Tag/Label and Inlay

    Removable RFID Reusable Label OS4216-U9

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Apparel / Retail / Logistics
    Details
    Product OS4025-F51
    ANTENNA SIZE(mm) 42*16mm
    Chip  FM13UF0051E
    EPC Memory 128Bits
    TID Memory 96Bits
    IC Life 100,000 programing cycles/50 years data retention
    RFID UHF Tag/Label and Inlay

    FM13UF0051E Chip UHF Label OS4025

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Library / Archives / Cable management / Smart filing cabinets
    Details
    Product OS331326-A
    ANTENNA SIZE(mm) 3*95mm
    Chip KX2005X-BL
    EPC Memory 96-240 Bits
    User Memory 1312 Bits
    Die-cut Dimension 100*10mm
    RFID UHF Tag/Label and Inlay

    UHF RFID Tag With LED Light

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Logistics
    Details
    Product OS4444-U8
    ANTENNA SIZE(mm) 44*44mm
    Chip  NXP UCODE 8 /NXP UCODE 9
    Real Range (FCC) 5m
    EPC Memory 128Bits/96Bits
    TID Memory 96Bits
    IC Life 100,000 programing cycles/50 years data retention
    APPLICATION SCENARIOS Logistics
    RFID UHF Tag/Label and Inlay

    Logistics RFID Label OS4444-U8

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Logistics
    Details
    Product OS5030-M4
    ANTENNA SIZE(mm) 30*50mm
    Chip Impinj Monza 4
    Real Range (FCC) 3.5m
    User Memory 512Bits
    EPC Memory 128Bits
    TID Memory 96Bits
    IC Life 100,000 programing cycles/50 years data retention
    RFID UHF Tag/Label and Inlay

    RFID Asset Tracking Tags OS5030-M4

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Logistics/Clothing/Check
    Details
    Product H47
    ANTENNA SIZE(mm) 44*44mm
    Chip Impinj Monza 4
    Real Range (FCC) 865MHZ:0.56m 920MHz:1.44m
    User Memory 512Bits
    EPC Memory 128Bits
    TID Memory 96Bits
    IC Life 100,000 programing cycles/50 years data retention
    RFID UHF Tag/Label and Inlay

    RFID Cloth Tag M4E

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Library / Cigarettes / alcohol
    Details
    Product OS0894-U8
    ANTENNA SIZE(mm) 8.15*94.8mm
    Chip  NXP UCODE 8 /NXP UCODE 9
    Real Range (FCC) 12m
    EPC Memory 128Bits/96Bits
    TID Memory 96Bits
    IC Life 100,000 programing cycles/50 years data retention
    RFID UHF Tag/Label and Inlay

    RFID Label For Warehouse OS0894-u8

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Apparel / Warehouse / Logistics
    Details
    Product OS1470-M700-A4
    ANTENNA SIZE(mm) 14*70mm
    Chip Impinj M730/Impinj M750
    Real Range (FCC) 12m
    User Memory -/32Bits
    EPC Memory 128Bits/96Bits
    TID Memory 96Bits
    IC Life 100,000 programing cycles/50 years data retention
    RFID UHF Tag/Label and Inlay

    RFID Logistics Label OS1470-M700-A4

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Assets / Logistics
    Details
    Product OS9503-H10
    ANTENNA SIZE(mm) 14*70mm
    Chip H10
    Real Range (FCC) 8m
    EPC Memory 128Bits/96Bits
    USER Memory 32(0)Bits
    IC Life 100,000 programing cycles/50 years data retention
    RFID UHF Tag/Label and Inlay

    RFID OS1470 H10 Tag For Logistics Tracking

    Rated 0 out of 5
    Read more
  • Download file
    Download
    Inquiry
    Applications: Logistics/Packing
    Details
    Product OS1993-M700
    ANTENNA SIZE(mm) 19*93mm
    Chip Impinj M730/Impinj M750
    Real Range (FCC) 12m
    User Memory -/32Bits
    EPC Memory 128Bits/96Bits
    TID Memory 96Bits
    IC Life 100,000 programing cycles/50 years data retention
    RFID UHF Tag/Label and Inlay

    RFID Logistics Sticker OS1993-M700

    Rated 0 out of 5
    Read more


OSRFID is a 20-year-old Chinese manufacturer specializing in RFID inlay and label R&D. Our factory supplies goods to numerous Chinese domestic businesses engaged in international trade.
We use Muehlbauer DDA-40K-WF to produce inlay, that can provide clients with high sensitivity and high quality products. OSRFID has 20 years of industry experience and can provide customized inlays for a variety of application scenarios.



1. Understanding RFID Labels

For new users or end brand customers, start by grasping the fundamentals of RFID labels. This includes understanding the different types of labels, the distinction between white labels and inlays, label categorization methods, label structure, the benefits of RFID tags over traditional tags, and more. Visit our RFID FAQ summary page for a quick overview.

2. Exploring RFID Applications

If you have a basic understanding of RFID tags but need more information about specific application scenarios, explore our categorized application scenarios and tag recommendations.

3. For Experienced RFID Users

Experienced RFID customers can directly download OSRFID’s related documents to quickly grasp our product line, technical expertise, and competitive advantages.
